Advanced 4-Motor Medical Bed for Safety and Comfort

The HAVEN Full Electric Homecare Bed is a high-quality medical bed designed to provide comfort, mobility, and safety for individuals with physical limitations or those needing extended care at home. With four quiet electric motors, caregivers or patients can easily adjust the bed’s height, backrest, legrest, and tilt angles to meet medical or personal needs. Built to meet European safety standards (EN 60601-2-52), this bed helps reduce risks such as falls and entrapment.

Made with durable materials, including an antibacterial-coated sheet metal surface and aluminum side rails, this hospital bed is designed for easy cleaning and long-lasting use. It features a cross-brake system with four smooth-rolling wheels (two with brakes), manual CPR functionality, and Trendelenburg positioning (head-down or feet-down tilt). The bed also includes a battery backup, a serum hanger with four hooks, and an optional nurse control panel for more advanced settings. Mattress not included.

Key Features:

Antibacterial electrostatic powder paint applied after nano-tech coating, cured at 356°F (180°C), with paint thickness between 1.57–3.54 mils (40–90 microns).
Manual CPR function included; compatible with LINAK and Dewert motors using single or double arm.
Bed-lying surface is constructed from sheet metal.
Serum hanger made of oxidized metal with 4 PA6 (polyamide) plastic hooks.
Trendelenburg and reverse Trendelenburg rails are made of aluminum.
Cross brake system with 4 wheels: 2 with brakes and 2 without.
Nurse control panel includes an activation button when using a 5 in (125 mm) diameter control box.

Product Specifications

Motors:	4 pcs.
Bed Dimensions:	41.73 in x 84.65 in (1060 mm x 2150 mm)
Lying Surface Height (Ground Clearance):	14.57 in to 31.50 in (370 mm to 800 mm)
Bed Extension Feature:	Yes
Adjustable Angles:	Backrest 70°, Calf 15°, Legrest 35°
Auto Regression:	3.93 in (100 mm)
Safety Patient Capacity:	606 lbs (275 kg)
Wheel Diameter:	4.92 in (125 mm), 5 wheels with mattress liner brake system
Trendelenburg/Reverse Trendelenburg Angles:	16° (min/max)
Additional Features:	Battery included, X-ray compatible backrest

Brochure

Nitrocare HAVEN Full Electric Homecare Bed
